New 74m motor yacht CRN 131 under construction at CRN Shipyard

CRN Shipyard, part of the Ferretti Group, specializing in the construction of ...

New 74m motor yacht CRN 131 under construction at CRN Shipyard

June 27, 2014

Written by Zuzana Bednarova

CRN Shipyard, part of the Ferretti Group, specializing in the construction of fully customized superyachts made of steel and aluminium, varying in size from 40 to 90 metres, is currently working on a new pleasure ship, the 74-metre motor yacht CRN 131. Luxury superyacht CRN 131 is destined to be the second biggest yacht to be built since the 80-metre flagship, mega yacht Chopi Chopi (CRN 129).

Rendering of the 74m mega yacht CRN 131

Rendering of the 74m mega yacht CRN 131

Hull number 131 of the shipyard, made of steel and aluminium, luxury yacht CRN 131 is being manufactured on the 13.50 metre naval platform, the same one that was used to build other important megayachts, such as the 72m CRN 124 superyacht “Azteca”.

Thanks to her five decks and a sub-deck, the CRN 131 yacht can comfortably accommodate up to 12 guests, in 5 guest cabins and the master suite, plus 4 staff persons in 2 cabins, and 34 crew members.

Super yacht CRN 131 is powered by two Caterpillar 3516 C-Chd 2’000 kW@1600 rpm engines, that allow her to navigate at a maximum speed of 16.5 knots and a cruising speed of 15 knots.

Among distinctive features of CRN 131 superyacht, which are also common to other CRN megayachts, are the innovative technologies and the open-air areas that create a new way of experiencing the sea, namely, the terrace in the master suite and the beach club: in fact, the stern hatch opens and transforms into a beach platform by the sea.

The simplicity of the CRN 74m lines contrasts with the great attention given to details in the linguistic definition and geometry of its superstructure and the furniture pieces in the different environments. The external lines were designed by Studio Zuccon International Project in close collaboration with the CRN Naval Engineering Department, and the internal layout by Andrew Winch Designs with CRN Interiors and Design Department.

As regards the design, the 74m motor yacht CRN 131 is the result of a research and analysis process aimed at optimizing the balance between internal and external spaces: the study carried out on the formal symmetry of the yacht in terms of volumes and proportions has created great comfort inside – developed so as to reduce the cubic content – with strong dynamism and essentiality of volumes and surface opening.

Moreover, light has a strategic role: artificial lighting and its presence in the areas is the key to the theoretical understanding of architecture.

Technical Specifications of luxury motor yacht CRN 131:

SHIPYARD CRN S.p.A.
MODEL CRN 74
YARD ID NUMBER CRN 131
HULL / SUPERSTRUCTURE Steel / Aluminium
TYPE Displacement hull
L.O.A. 74.00 m
L.B.P 63.00 m
MOULDED BEAM 13.50 m
DRAFT 3.40 m
MOULDED DEPTH 6.60 m
FULL LOAD DISPLACEMENT 1’650 t
DEADWEIGHT 280 t
GROSS TONNAGE 2194 GT
GUEST N° 12 persons (5 double cabins + 1 owner suite)
CREW N° 34 persons
FUEL TANK 250’000 lt
FRESH WATER 50’000 lt
FRESH WATER PRODUCTION 16’000 lt/day
MAIN ENGINE 2xCATERPILLAR 3516C-Chd 2000 kW@1600 rpm
MAIN GENERATORS 2XCATERPILLAR C18 275 kW 380V 50Hz 1XCATERPILLAR C9 175 Kw 380V 50 HZ
EMERGENCY GENERATOR 1 x CATERPILLAR C4.4 118 kW 380V 50Hz
MAX SPEED (half load) 16.5 knots
CRUISING SPEED ( @ 85%MCR) 15 knots
RANGE @ 12 knots/15 knots 6’000 nm/4’000 nm
MAX NOISE @ CRUISING SPEED IN ROOMS 55 dB(A)
HELICOPTER PLATFORM SUITABLE FOR 3000 KG HELICOPTERS
NAVAL ARCHITECTURE CRN ENGINEERING
EXTERIOR DESIGN ZUCCON INTERNATIONAL PROJECT
INTERIOR DESIGN ANDREW WINCH DESIGNS
CLASSIFICATION Lloyd’s Register of Shipping  LR  100 – A1 – SSC – “Y”, MONO, G6,  LMC,UMS MCA LY2 compliance
