A General Description of Motor Yacht LOTUS

LOTUS was previously registered as project/yacht name Newcastle Voyager. This 38 m (126 foot) luxury yacht was developed at Newcastle Marine in 2002. Motor Yacht LOTUS is a well proportioned superyacht. She could be considered a recent converted private yacht. The firm of naval architecture that made her design work for this ship was Dejong & Lebet and Luiz De Basto Designs and Murray & Associates. The original interior design work is the work of the talented Luiz De Basto Designs. Luxury yacht LOTUS is a interesting yacht that is able to accommodate up to 10 people on board and has around 6 qualified crew.

Building & Naval Architecture relating to Luxury Yacht LOTUS

Dejong & Lebet was the naval architecture company involved in the technical superyacht design work for LOTUS. Also the company Dejong & Lebet and Luiz De Basto Designs and Murray & Associates expertly collaborated on this venture. Interior designer Luiz De Basto Designs was employed for the creative internal styling. the United States is the country that Newcastle Marine completed their new build motor yacht in. After the formal launch in 2002 in Palm Coast Fl she was delivered on to the yacht owner after sea trials and testing. Her main hull was crafted from steel. The motor yacht superstructure component is made mostly using aluminium. With a beam of 8.53 metres or 28 feet LOTUS has spacious internal space. A reasonably shallow draught of 2.35m (7.7ft) limits the amount of worldwide harbours she can visit, contingent on their individual depth at low tide.

Engines & Speeds On M/Y LOTUS:

The 3406E engine installed in the motor yacht is produced by CATERPILLAR. Coupled to the LOTUS engines are twin screw propellers. The engine of the yacht gives 600 horse power (or 442 kilowatts). She is fitted with 2 engines. The combined power for the boat is accordingly 1200 HP / 883 KW. As for stabalisers she uses Abt. The bow thrusters are Abt.

On board Superyacht LOTUS There is Passenger Accommodation Potential:

Providing room for a limit of 10 welcome guests overnighting, the LOTUS accommodates them in luxury. Normally the vessel requires approximately 6 expert yacht crew to run.

A List of the Specifications of the LOTUS:

Superyacht Name:Motor Yacht LOTUS
Ex:Newcastle Voyager
Built By:Newcastle Marine Inc.
Built in:Palm Coast Fl, United States
Launched in:2002
Length Overall:38.3 metres / 125.7 feet.
Naval Architecture:Dejong & Lebet and Luiz De Basto Designs and Murray & Associates, Dejong & Lebet
Designers Involved in Yacht Design:Luiz De Basto Designs
Interior Designers:Luiz De Basto Designs
Hull / Superstructure Construction Material:steel / aluminium
Owner of LOTUS:Unknown
LOTUS available for luxury yacht charters:-
Is the yacht for sale:-
Helicopter Landing Pad:No
Material Used For Deck:steel-teak
The Country the Yacht is Flagged in:St Vincent & Grenadines
Official registry port is:Kingstown
Home port:Palm Coast Fl, USA
Max yacht charter guests:10
Number of Crew Members:6
The propulsion comes from two 600 Horse Power / 442 kW Caterpillar. Engine Model: 3406E diesel.
Total engine power output 1200 HP /883 KW.
Cruising at a speed of 12 nautical miles per hour.
Top Speed: 14 knots.
Range in nautical Miles is 3500 at a speed of 10 knots.
Fuel tanks: 54126 L.
Water: 23656.00.
Power generation: Northern Lights 2 times 80 kilowatts.
Stabalisers: Abt.
Bow Thrusters: Abt.
Yacht Beam: 8.53m/28ft.
Draught Maximum: 2.35m/7.7ft.
Yacht Type: converted private yacht.

Miscellaneous Yacht Details

She has a steel-teak deck.
