A Summary of Motor Yacht KARYATIS

The motor yacht KARYATIS is a 32 m 105 (ft) well proportioned aluminium ship which was constructed at Heesen Yachts and concieved by Heesen and Pieter Beeldsnijder Design. Accommodating 6 passengers and 4 crew, motor yacht KARYATIS is ex 12532. This private superyacht has been designed from the naval architecture of Heesen and Pieter Beeldsnijder Design. Pieter Beeldsnijder Design was involved in the interior design and styling.

The Construction & Design for Luxury Yacht KARYATIS

Heesen was the naval architect firm involved in the formal vessel design work for KARYATIS. Her interior design was conceived by Pieter Beeldsnijder Design. Heesen and Pieter Beeldsnijder Design is also associated with the yacht general design work for this boat. Built by Heesen Yachts the vessel was constructed in the Netherlands. She was officially launched in Oss in 2005 before being transferred to the owner. The main hull was constructed with aluminium. The motor yacht superstructure component is fabricated extensively with aluminium. With a width of 8 m / 26.25 feet KARYATIS has spacious interior. She has a fairly shallow draught of 2.1m (6.89ft).

M/Y KARYATIS Engines And Performance:

Powered by twin MTU diesel main engines, KARYATIS is able to reach a top speed of 30 knots. Connected to her MTU engine(s) are twin screw propellers. She also has an economical range of 1000 miles whilst underway at her cruising speed of 20 knots. Her total HP is 7292 HP and her total Kilowatts are 5440.

The Guest Accommodation On Aboard Superyacht KARYATIS:

The good sized luxury yacht M/Y KARYATIS is able to sleep as many as 6 passengers in addition to 4 crew.

A List of the Specifications of the KARYATIS:

Superyacht Name:Motor Yacht KARYATIS
Ex:12532
Built By:Heesen Yachts
Built in:Oss, Dutch
Launched in:2005
Length Overall:32 metres / 105 feet.
Naval Architecture:Heesen and Pieter Beeldsnijder Design, Heesen
Designers Involved in Yacht Design:Pieter Beeldsnijder Design
Interior Designers:Pieter Beeldsnijder Design
Gross Tonnes:228
Displacement:150
Hull / Superstructure Construction Material:aluminium / aluminium
Owner of KARYATIS:Unknown
KARYATIS available for luxury yacht charters:-
Is the yacht for sale:-
Helicopter Landing Pad:No
Material Used For Deck:teak
The Country the Yacht is Flagged in:United States
Class society used:LR (Lloyds Register)
Max yacht charter guests:6
Number of Crew Members:4
Her Engine(s) is two 3646 HP / 2720 Kilowatts MTU. The Model type is 16V 4000 M90 diesel.
Overall output: 7292 HP /5440 KW.
Approximate Cruise Speed is 20 knots.
Top Speed: 30 nautical miles per hour.
Range: 1000 at a speed of 20 knots.
Fuel tanks: 20000 L.
Fresh water: 4800.00.
Air Conditioning: Heinen & Hopman.
Yacht Beam: 8m/26.25ft.
Draught Maximum: 2.1m/6.89ft.

Further Information On The Yacht

The yacht was supplied with Heinen & Hopman air con. This motor yacht has a teak deck.
