Claydon Reeves and Dysktra Naval Architects have worked together on the 46m sailing yacht Exo. Designed to add a new element to the experience of performance cruising, the Exo superyacht provides magnificent views of the external as well as underwater environments.
Claydon Reeves and Dykstra Naval Architects have brought a more organic and natural approach to the 46m luxury yacht Exo inspired by shapes and forms not usually found in traditional yacht design with its linear form language. The interconnected root structures of large trees seemed like a good starting point as the basis for a yacht. Not only does the long vertical trunk represent the mast, but the root ball forms the hull, providing strength and the support for the vertical structure.
Designers also considered the skeletal structure of small but strong creatures. In nature it is the exo-skeleton which provides the ‘chassis’ for these organisms. These exo-skeletons do not employ straight lines but instead have twisting and turning curves which imbue the creature with optimal strength – their forms defined by millions of years of evolution.
By setting aside some of the established thinking of past projects, designers strived for a new aesthetic that was both attractive and buildable.
All technical and structural elements are integrated into the design so that the typically engineered solutions such as boom, helm stations and spreader bars share a consistent organic aesthetic. The main load bearing elements are constructed from a carbon monocoque space frame, much like that of a modern motorbike, whilst the hull skin are to be developed using lighter construction methods. Even the deck caukling is based upon the radiating growth rings of a tree trink, which illuminate at night, forming intriguing patterns and effects. The twin helm positions grow out of the bulwarks like tree branches.
The huge glass windows wrap over into the deck and are framed by the carbon fibre ‘chassis’ that is futher accentuated by the bold material breakup. The cockpit maintains the organic form language; the sofas providing undulating islands of soft expansive seating and the table forms appear eroded by the sea.
As one moves rearward the decks gently step down, firstly with a concave cut-out and then approaching the stern a convex wall of glass that defines the edge of the aft beach club and saloon.
The concept is perhaps best explored and udnerstood from inside the Exo yacht where one can fully appreciate the implications of the new design approach. The main objective with this yacht was to allow fat greater amounts of light into the interior and to provide ground breaking views of the passing environments. The carbon chassis is apparent internally and the organic mullions that separate the massive glass panels imbue the interior with the sensation of being contained within the ribcage of a large aquatic creature. To futher emphasise this feeling, the interior architecture of the main saloon suggests being partially separated from the hull structure, giving the impression of a soft cocoon floating within a rigid structure. The seating and furniture have been designed with an integrated philosophy of organic forms and subtle level changes delineate the different areas.
The material pallet is a combination of strong technical carbon fibre and the softness of natural woods, wools and silks bathed in subtle lighting that accentuates the key design elements.
Specifications of the 46m superyacht Exo by Claydon Reeves and Dysktra Naval Architects:
Length Overall 46,00m
Length Waterline 42,73m
Mast construction Carbon spars & rigging
Accommodation 8 Guests in 1 double & 3 twin cabins – 7/8 Crew in 1 double & 3 bunk cabins
